YX845&900 double-layer Roof Panel Forming Machine
1. Main features of roof panel forming machine
The advantages of roof panel machine are as follows:
1. Produce different roof panel size in one machine
2. Save space, more convenient.
3. Easy operation, low maintenance cost
4. Stable and durable, Sea freight for import can be saved by 50%
2. Detailed Images of YX845&900 roof panel forming machine
Machine Parts
1) YX845&900 double layer roof panel machine feeding guide
Brand: BMS Original: China
Make material feeding more smoothly
2) YX845&900 double layer roof panel machine rollers
Brand: BMS Original: China
Rollers manufactured from high quality bearing steel GCr15, CNC lathes, Heat Treatment.
with black treatment or Hard-Chrome Coating for options.
With feeding material guide, body frame made from 300# H type steel by welding
3) YX845&900 double layer roof panel machine post cutter
Brand: BMS Original: China
Made by high-quality mold steel Cr12 with heat treatment
Cutter frame made from high quality 25mm steel plate by welding
Hydraulic motor:2.2 KW, Hydraulic pressure range: 0-16Mpa
4) YX845&900 double layer roof panel machine touching screen
Brand: BMS Original: China
Easy to operate
5) YX845&900 double layer roof panel machine decoiler
Brand: BMS Original: China
Manual Decoiler: one set
Un-powered, manually control steel coil inner bore shrinkage and stop
Max. feeding width: 1250mm, coil ID range 470mm±30mm
Capacity: Max. 8 Ton
With 6 tons hydraulic decoiler for option
6) YX845&900 double layer roof panel machine exit rack
Brand: BMS Original: China
Un-powered, one unit
Other detailes of YX845&900 double layer roof panel machine
Suitable for material with thickness 0.3-0.8mm
Shafts manufactured from 45#, Main shaft diameter=φ75mm, precision machined
Motor driving, Gear chain transmission,14/9 forming stations
Main motor=5.5KW, Frequency speed control. Forming speed of approx.12-15m/min
PLC Control System (Touch screen brand: German Schneider Electric/Taiwan WEINVIEW,
Inverter brand: Finland VOCAN/Taiwan DELTA/ALPHA, Encoder brand: Japan Koyo/OMRON)
Combined with: PLC, Inverter, TouchScreen, Encoder, etc
Cut-to-length tolerance≤±2 mm
Control Voltage 24V
User's manual in English
For the more detail click here to see the video:
http://www.rollforming-machinery.com/Quick-change-Type-C-Purlin-Roll-Forming-Machine_n26
After-sale service of roof panel machine
1. The warranty of the roof panel machine
is one year after the client receives the machine.
Within one year, we will courier the replacement parts to the client free of charge.
2. We offer technical support for the entire life of our machines.
3. We can send our technicians to install and train the workers in the clients' factories at extra cost.
Terms of trade
1. Minimum order quantity (MOQ): 1 piece
2. Delivery time: about 30 workdays
3. Port of loading: port of Xiamen
4. Type of payment: by T/T or by L/C
5. Export: Australia, UK, Ireland, Mexico, Brazil, Israel, Dubai, Russia, India, Taiwan, Singapore,
Malaysia, Thailand, Philippines, Myanmar, Vietnam, South Africa, Mozambique,
Zambia, Zimbabwe, Nigeria, Egypt, Sudan, etc.
